ProCarve knee joint

Item #: 3R2
Log in to order

Overview

The ProCarve sports prosthetic system includes a monocentric, aluminium sports knee equipped with a highperformance hydraulic damping element and a disengagement function to make sitting down more comfortable. The damping element – a combination of a pneumatic spring and a hydraulic unit – ensures dynamic movement. The individually adjustable air pressure controls the flexion movement and the hydraulics dampen the extension movement. When re-engaged, the flexion angle is limited to 67°. In order to sit down, the user can bend the knee joint easily without damping simply by pulling on the attached belt. The maximum flexion angle when disengaged is 80°. Together with the ProCarve foot component, this provides a targeted and coordinated system solution for users with an aboveknee amputation or knee disarticulation.

Specifications

Maximum Body Weight 220 lbs (100 kg)
Material Aluminum
Proximal Connection Pyramid Adapter
Maximum Knee Flexion Angle 80 degrees locked / 67 degrees unlocked
System Height 241 mm
Product Weight 1,990 g (4.39 lbs)
Build Height 277 mm
Distal Build Height 225 mm
Proximal Build Height 52 mm

Documents

Refine results

LLP Prosthetist Documentation

Reimbursement: Documentation Guide

Reimbursement

PDF Document | Published: Apr 17, 2023

LLP Physician Documentation Guide

Reimbursement

PDF Document | Published: Apr 17, 2023

1E2, 3R2 ProCarve - Safety Instructions

Product Information

PDF Document | Published: Jan 1, 2014

Sports Feet Poster

Product Information

PDF Document | Published: Nov 1, 2018

ProCarve – the system

Product Information

PDF Document | Published: Dec 1, 2013

ProCarve

Product Information

PDF Document | Published: Dec 1, 2013
