Scope of delivery:
Does not include (2R57) 34mm pylon, please purchase separately
* Additional versions of the 4X147 Functional Ring can be ordered separately
| Activity level | K2, K3, K4 |
|---|---|
| Pump mechanism | Functional ring |
| Amputation type | Transtibial |
| Weight range | 88 - 276 lbs (40 - 125 kg) |
| Vacuum (max.) | 650 mbar / 20 inHg |
| Clearance | 117 mm |
| Proximal connection | Pyramid Receiver |
| Distal connection | 34 mm tube clamp |
| Pump Weigth | 425 g |
| Pump Height | 117 mm (4.6in) |
| Pump System Height | 175 mm (6.9 in) |
| Torques | Receiver Set Screws (Fig. 2, items 7 & 8): 15 Nm (133 in-lbs) Clamp Ring Screw (Fig. 2, item 9): 10 Nm (88 in-lbs) Retaining Screw (Fig. 5, item 10): 7 Nm (60.0 in-lbs) |
| Material | Aluminium/Titanium/Nylon |
| Body Weight | Recommended Functional Ring | Item Number |
|---|---|---|
| 88 - 103 lbs (40 - 47 kg) | 0 | 4R147=0 |
| 104 - 121 lbs (48 - 55 kg) | 1 | 4R147=1 |
| 122 - 143 lbs (56 - 65 kg) | 2 | 4R147=2 |
| 144 - 165 lbs (66 - 75 kg) | 3 | 4R147=3 |
| 166 - 192 lbs (76 - 87 kg) | 4 | 4R147=4 |
| 193 - 220 lbs (88 - 100 kg) | 5 | 4R147=5 |
| 221 - 247 lbs (101 - 112 kg) | 6 | 4R147=6 |
| 248 - 276 lbs (113 - 125 kg) | 7 | 4R147=7 |
