Overview
The lightweight Terion K2 1C11 provides users of low to moderate mobility with confidence at every step.
- Aluminum Adapter - Lightweight and durable
- Split toe fiberglass spring - Good balance of flexibility and dynamic response with durability.
- The split forefoot provides control on uneven surfaces
- Foam Base - Cushioned heel strike and controlled rollover
- Lightweight design - Only 325g without footshell makes it one of the lightest K2 feet on the market
- High weight limit:
- Sizes 26 to 30 have a high weight limit of 385 lbs / 175 kg
- Sizes 24 to 25 have a weight limit of 330 lbs / 150 kg
- Sizes 22 to 23 have a weight limit of 220 lbs / 100 kg
The lightweight Terion K2 1C11 provides users of low to moderate mobility with confidence at every step. The foam base allows for a cushioned heel strike, smooth rollover and safe ground contact.
A fiberglass spring offers forefoot stability and supports a gait pattern characterised by flexibility and adequate dynamics. The split toe design offers moderate medio-lateral flexibility and a high degree of safety on uneven terrains.
Benefits:
- Lightweight, stable and supportive foot design: meeting the demands of low to moderate mobility users
- Easy to fit: low profile footshell with alignment marks and easy access to alignment screws
- Universal application: low clearance and maximum patient weight up to 385 lbs / 175 kg (depending on size)
- Robust design: durable, resistant against dust, dirt and splashwater
Specifications
Activity Level | K1, K2 |
---|---|
Maximum Body Weight | 385 lbs (175 kg) |
Heel Height | 10 +/- 5 mm |
Footshell Color | Beige (4), Brown (15) |
Footshell Shape | Normal (N), Slim (S) |
Side | Right (R), Left (L) |
Sizes | 22 cm - 30 cm |
Product weight (without footshell) | approx. 325 g |
Product weight (with footshell) | approx. 573 g |
~ Min. Clearance Height (Slim, Size 22-23) | 68 mm (2.677") |
~ Min. Clearance Height (Normal, Size 24-25 cm) | 59 mm (2.323") |
~ Min. Clearance Height (Normal, Size 26-27 cm) | 65 mm (2.560") |
~ Min. Clearance Height (Normal, Size 28 cm) | 67 mm (2.638") |
~ Min. Clearance Height (Normal, Size 29-30 cm) | 70 mm (2.756") |
22 cm | 23 cm | 24 cm | 25 cm | 26 cm | 27 cm | 28 cm | 29 cm | 30 cm | |
---|---|---|---|---|---|---|---|---|---|
Up to 121 lbs (up to 55 kg) | 1 (S) | 1 (S) | 1 (N) | 1 (N) | 2 (N) | 2 (N) | 2 (N) | ||
122 to 166 lbs (56 - 75 kg) | 2 (S) | 2 (S) | 2 (N) | 2 (N) | 2 (N) | 2 (N) | 2 (N) | ||
167 to 221 lbs (76 - 100 kg) | 3 (S) | 3 (S) | 3 (N) | 3 (N) | 3 (N) | 3 (N) | 3 (N) | 3 (N) | 3 (N) |
222 to 276 lbs (101 - 125 kg) | 4 (N) | 4 (N) | 4 (N) | 4 (N) | 4 (N) | 4 (N) | 4 (N) | ||
277 to 330 lbs (126 - 150 kg) | 5 (N) | 5 (N) | 5 (N) | 5 (N) | 5 (N) | 5 (N) | 5 (N) | ||
331 to 385 lbs (151 - 175 kg) | 6 (N) | 6 (N) | 6 (N) | 6 (N) | 6 (N) |
