Dynamic Foot with Toes

Item #: 1D10

Added to your shopping cart

Overview

The 1D10 Dynamic Foot features natural shape with smooth surface, shaped toes and sandal toe. The functional characteristic are achieved through the proven combination of a contoured core and functional foam. This results in a comfortable heel strike and a smoother rollover than with the SACH foot. The sophisticated foam technology offers improved dynamic characteristics of the forefoot.

The 1D10 is available with or without an assembled titanium modular adapter.

Specifications

Activity Level	K1, K2
Maximum Body Weight	330 lbs (150 kg)
Footshell Color	Beige (4), Brown (15)
Footshell Shape	Normal (N)
Side	Right (R), Left (L)
Sizes	22 cm - 30 cm
Product weight (w/o footshell)	385 g - 780 g
~ Min. Clearance Height (w/o adapter)	90 mm (3 1/2")
Heel Height	10 +/- 5 mm

Without Adapter
Size	Max. Body Weight	Heel Height	Minimum Clearance Height (approx.) (without Adapter)	Product Weight (w/o Adapter), approx.	Color Options (Footshell)	Article Number (Left)	Article Number (Right)
22 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	290 g	beige (4) brown (15)	1D10=L22-0-W/(color)	1D10=R22-0-W/(color)
23 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	320 g	beige (4) brown (15)	1D10=L23-0-W/(color)	1D10=R23-0-W/(color)
24 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	350 g	beige (4) brown (15)	1D10=L24-0-W/(color)	1D10=R24-0-W/(color)
25 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	390 g	beige (4) brown (15)	1D10=L25-0-W/(color)	1D10=R25-0-W/(color)
26 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	470 g	beige (4) brown (15)	1D10=L26-0-W/(color)	1D10=R26-0-W/(color)
27 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	505 g	beige (4) brown (15)	1D10=L27-0-W/(color)	1D10=R27-0-W/(color)
28 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	565 g	beige (4) brown (15)	1D10=L28-0-W/(color)	1D10=R28-0-W/(color)
29 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	605 g	beige (4) brown (15)	1D10=L29-0-W/(color)	1D10=R29-0-W/(color)
30 cm	275 lbs / 125 kg	10 +/- 5 mm	90 mm	685 g	beige (4) brown (15)	1D10=L30-0-W/(color)	1D10=R30-0-W/(color)

With Adapter
Size	Max. Body Weight	Heel Height	Min. Clearance Height (w/o Adapter)	Product Weight (approx.)	Color Options (Footshell)	Article Number (Left)	Article Number (Right)
22 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	385 g	beige (4) brown (15)	1D10=L22-0-P/(color)	1D10=R22-0-P/(color)
23 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	415 g	beige (4) brown (15)	1D10=L23-0-P/(color)	1D10=R23-0-P/(color)
24 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	445 g	beige (4) brown (15)	1D10=L24-0-P/(color)	1D10=R24-0-P/(color)
25 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	485 g	beige (4) brown (15)	1D10=L25-0-P/(color)	1D10=R25-0-P/(color)
26 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	565 g	beige (4) brown (15)	1D10=L26-0-P/(color)	1D10=R26-0-P/(color)
27 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	600 g	beige (4) brown (15)	1D10=L27-0-P/(color)	1D10=R27-0-P/(color)
28 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	660 g	beige (4) brown (15)	1D10=L28-0-P/(color)	1D10=R28-0-P/(color)
29 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	700 g	beige (4) brown (15)	1D10=L29-0-P/(color)	1D10=R29-0-P/(color)
30 cm	330 lbs / 150 kg	10 +/- 5 mm	3.5 in / 90 mm	780 g	beige (4) brown (15)	1D10=L30-0-P/(color)	1D10=R30-0-P/(color)
