TPE LINER
Item #: 6Y92=KDétails du produit
A cylindrical shaped, textile-covered cushion liner made from a thermoformable copolymer, ideal for use with a full contact socket:
- For transtibial amputees with low to moderate activity level
- Ideal for use in combination with a valve and sealing sleeve
- Also available with distal connector (6Y90=*) for use with a locking/lanyard system
- Textile coating has no exterior seams that could separate
- Made of moldable thermoplastic material (thermoplastic elastomer, or TPE) for use with atypical residual limb shapes
- 10 mm distal cushion pad and wall thickness tapering from 5 mm to 3 mm proximal for protection against socket forces
- Copolymer contains medical grade mineral oil to moisturize dry skin and an antioxidant that traps free radicals and hydroxyl groups
Sizing:
Measure the residual limb circumference 4 cm above the distal end of the residual limb and select the liner size which corresponds to this measurement, or the next smallest size.
Serial number location: Serial number is printed on the outside of the liner on the textile at the distal end.
Try our Interactive Liner Selection Tool here: https://academy.ottobockus.com/toolbox/liners/liners
Accessories
Documents
Liner Comparison Card
Experience the Difference of Ottobock Liners
Information produit
Document PDF | Date de publication : 1 mars 2018
